Low Pitch Lean To Conservatory Roof Kit

A made to measure white Ultraframe classic lean to conservatory roof kit.

low pitch lean to roof
Sizes
Colour
Glazing Type
Survey Details
Extras

Sizes

  • Enter Width (mm) *

    Min: 1000Max: 5000

  • Enter Projection (mm) *

    Min: 1000Max: 3750

  • White Price *

  • Smooth Grey White Price *

  • Smooth Grey Price *

  • Foiled Grey Price *

  • Foiled Grey White Price *

  • rosewood on white *

  • rosewood *

  • light oak on wh *

  • lightoak *

  • blackonwh *

  • black *

  • irishoakwh *

  • irishoak *

  • greenonwh *

  • green *

Next

Colour

  • Roof Colour *

  • Is the roof the same colour inside and out? *

PreviousNext

Glazing Type

  • Please select type of glazing *

  • Please select a glass option *

  • Please select a polycarbonate option *

  • ambi blue price *

  • ambi sunshade *

  • 25mmpoly *

  • 35mmpoly *

PreviousNext

Survey Details

  • Pitch *

    Min: 3Max: 5

  • Wall Details *

PreviousNext

Extras

Previous

CLASSIC LOW PITCH LEAN-TO

This lean to roof system enables for roof fitment as low as 2.5°. It lets you to attach a lean-to conservatory to even the most problematic bungalow situation by using ready-made firrings or your own raked frames.



low pitch lean to eaves beam









low pitch lean to wallplateFeatures & Benefits

• Available in two polycarbonate glazing options
- 25 and 35mm or unglazed for 4-16-4 units
• Fully variable pitch (2.5° to 10°)
• 3 colour options – White, Rosewood and Light Oak
(internal and external)
• Structural firrings at 2.5° and 5° are available in the 3 colour options
• Suitable for raked frames too
• Tested and approved by the BBA down to 2.5° degrees
• Integrated wall plate ventilation system for additional comfort
• Optional box gutter allows ‘work arounds’ on restricted soffit situations





For help and guidance with detailing or specification please contact our roof technical support team on:-
Tel: 0345 619 7733 or Email: hello@conservatoryroofshop.co.uk

Low Pitch Lean To Roof Install Guide

Classic Low Pitch Installation Guide
